You're just one step to turn your TV into Smart TV
Operation System
Kodi
Kodi, formally known as XBMC, is a multimedia player platform that allows users to play and view most videos, music, such as Internet podcasts, home networks and all common media media files. local and network storage. The ATV 329x comes pre-installed Kodi custom and optimized, with hardware decoding up to 4K2K Ultra HD support.
WiFi AC + Bluethoot
3x Wifi speed faster than Wireless-N Wi-Fi 150% wide / Ultra wide coverage for large homes and multi-storey location with less interference.
4K2K / ULTRA HD @ 60fps
4K2K Ultra HD video playback / decoding in real time, with HDMI 2.0 frame rate can go up to 60fps. Enjoy incredible picture clarity and dramatic details 4K2K Ultra HD and 1080p resolution.
H.265 hardware decoding, 50% bandwidth savings
H.265 / HEVC is a successor to H.264 / AVC. Compare to H.264, the H.265 data compression ratio is double at the same video quality level. It may alternatively be used to provide substantially improved video quality at the same bit rate.
10-bit color decoding
10-bit color decoding, maximum support of 1.7 billion color depth, 60 times more than normal 8-bit color decoding. It gives you a more natural and more realistic image color.
HDR (High Dynamic Range) Video
ATV329X supports HDR10 technology.
With HDR technology you can watch video with intense contrast, clarity and clarity
* Requires HDR TV and HDR content video
MyGica Share
MyGica Share is a multi-screen interactive application.
MyGica shares media streaming functions, document file archives, AirPlay Mirroring and Miracast functions.
You can easily stream your media from your mobile devices and PC to TV.
OTA Update
MyGica Andoid TV Platforms / Solution benefits from MyGica's secure online update service to always provide the latest, secure and excellent firmware and application that are available.
Features
- ARM® Cortex ™ -A53 quad-core up to 2GHz
- Penta-core ARM Mail GPU up to 750MHz
- Developed by Android 6.0, frmware upgrade support
- HEVC H.265 Support
- VP9 Profle-2 up to 4K x 2K @ 60fps
- Support UHD 4K 60fps HW decoding
- 2G RAM, 8G EMMC
- HDMI2.0 video output
- Supports Motion mouse and keyboard input
System requirements
- TV with HDMI input.
- For WiFi, router with N support preference.
Package contents
- ATV329x
- HDMI cable
- AV cable
- User Manual
- Power adapter
- Remote control
Specification
| Product | Mygica Android 6.0 TV box ATV329X |
| CPU | Quad Core 64bit ARM Cortex - A53 |
| Frequency | 2 GHz |
| RAM | DDR3-2GB |
| Almacenamiento | 8GB EMMC |
| OS | Android 6.0 |
| Función principal | |
| UI | Mygica estilo de interfaz de usuario de Android 6.0 |
| Navegador | Google Chrome |
| Reproductor multimedia | Reproducción de video local: VP9, Mpeg1 / 2/4, H.264, H.265, VC-1, WMV, AVI, MKV, |
| Vídeo en línea | Acceso a Internet, reproducción de videos en línea |
| Música | Reproductor de música local: MP3, WAV, WMA |
| Música en línea | Acceso a Internet, reproducción de música en línea |
| Visor de imágenes | Soporte de múltiples formatos:BMP,JPG,TIF,PNG,GIF |
| Software update | OTA or local update by USB pen drive or Micro SD Card |
| External storage | Micro SD card, USB storage support |
| Bluethoot | Bluethoot-4.0 |
| Wi-Fi | 802.11ac |
| Mirroring | DLNA, Miracast |
| Interface denition and parameter | |
| USB | 2x USB2.0 port |
| SD card | 1xMicro SD slot max128GB |
| Rj45 | Wire internet connecting, RJ45 10/100 Megabits |
| HDMI | HDMI 2.0 output |
| CVBS | CVBS Output |
| Remote control | Mygica IR remote (KR21) |
| Voltage | 5V/2A DC |
| Resolution | 4K.2K,1080P,1080i, 720P, 720i, 576P, 576i, 486P, 486i |
| Product Size | 1000mm(L)* 106mm(W)*24mm(T) |
| Net weight | 147g |
| Power Consumption | ≥6W |
| Remote Distance | 8 Meters Visual |
| CPU (Processor) | Amlogic S905X Quad Core Cortex-A53 a 2.0GHz |
| GPU (Graphics) | Penta Core 5x Mali 450MP a 2GHz (HDR) |
| RAM memory | 2GB DDR3 Dual |
| Internal memory | 8GB expandable by SD |
| Operating system | Android 6.0 Marshmallow |
| Wi-Fi | b/g/n/ac Dual 5Ghz |
| WIFI antenna | 1x External |
| Ethernet | Gigabit 1000 Mbps |
| Bluetooth | Internal 4.0 |
| WiFi Hotspot | Yes |
| H.265 Hardware decoding | Yes |
| Video output | HDMI |
| Card reader | SD |
| Video Resolution | UltraHD 4K 3840p |
